Double Sealed Recessed Manhole Covers

1 review

DESCRIPTION

Double Sealed Recessed Manhole Covers are a quality product made to BS:EN124 standards using 99.9% pure aluminium, all cover seals are made with EDPM and all screws are stainless steel. The mild steel base has a loading of up to 75kN/5Tons
The cover is waterproof and self secured to the outer frame. The unique second seal provides an additonal odour barrier, as well as elasticity to avoid tension between the cover & frame and also prevents dirt build up between these to make for easy cover removal.
Features include lifting keys and reinforced mesh, extruded aluminium frame, lifting holes covered with plastic caps.

Sizes available, please check all dimensions before ordering.

DS-60-300 x 300mm Overall Size L360 x W360mm Clear Opening L300 x W300mm Overall Depth 60mm In Tray Depth 48mm
DS-60-450 x 450mm Overall Size L510 x W510mm Clear Opening L450 x W450mm Overall Depth 60mm In Tray Depth 48mm
DS-60-600 x 450mm Overall Size L660 x W510mm Clear Opening L600 x W450mm Overall Depth 60mm In Tray Depth 48mm
DS-60-600 x 600mm Overall Size L660 x W660mm Clear Opening L600 x W600mm Overall Depth 60mm In Tray Depth 48mm
DS-80-300 x 300mm Overall Size L360 x W360mm Clear Opening L300 x W300mm Overall Depth 80mm In Tray Depth 68mm
DS-80-450 x 450mm Overall Size L510 x W510mm Clear Opening L450 x W450mm Overall Depth 80mm In Tray Depth 68mm
DS-80-600 x 450mm Overall Size L660 x W510mm Clear Opening L600 x W450mm Overall Depth 80mm In Tray Depth 68mm
DS-80-600 x 600mm Overall Size L660 x W660mm Clear Opening L600 x W600mm Overall Depth 80mm In Tray Depth 68mm
DS-60-750 x 600mm Overall Size L810 x W660mm Clear Opening L750 x W600mm Overall Depth 60mm In Tray Depth 48mm
DS-60-750 x 750mm Overall Size L810 x W810mm Clear Opening L750 x W750mm Overall Depth 60mm In Tray Depth 48mm
DS-80-750 x 600mm Overall Size L810 x W660mm Clear Opening L750 x W600mm Overall Depth 80mm In Tray Depth 68mm
DS-80-750 x 750mm Overall Size L810 x W810mm Clear Opening L750 x W750mm Overall Depth 80mm In Tray Depth 38mm
DS-60-900 x 600mm Overall Size L960 x W660mm Clear Opening L900 x W600mm Overall Depth 60mm In Tray Depth 48mm
DS-60-900 x 900mm Overall Size L960 x W960mm Clear Opening L900 x W900mm Overall Depth 60mm In Tray Depth 48mm
DS-60-1000 x 1000mm Overall Size L1060 x W1060mm Clear Opening L1000 x W1000mm Overall Depth 60mm In Tray Depth 48mm
DS-80-900 x 600mm Overall Size L960 x W660mm Clear Opening L900 x W600mm Overall Depth 80mm In Tray Depth 68mm
DS-80-900 x 900mm Overall Size L960 x W960mm Clear Opening L900 x W900 Overall Depth 80mm In Tray Depth 68mm
DS-80-1000 x 1000mm Overall Size L1060 x W1060mm Clear Opening L1000 x W1000mm Overall Depth 80mm In Tray Depth 68mm
Bespoke sizes available, get in touch for more information.

Contractors must ensure that products are fit for purpose - if in doubt, please get in touch

Disclaimer

Thank you to all our clients for providing images of products we have supplied, sadly we can not individually thank each company on our website.

Please note delivery prices are as accurate as possible at time of ordering, however this cost may be subject to change at any time due to weight/volume, fuel surcharges, currency changes and location.
Please let us know about any access restrictions at the delivery/check-out stage as failure to provide information may delay your order or incur extra delivery costs.
All materials are subject to availability at the time of order. The administration team will be in touch to arrange/advise of your delivery date.
The administration team will contact you should any issue arise concerning delivery charges.
Please allow enough material including wastage for your project(s)

Contact Arbour Landscape Solutions for more information.
