Ground Reinforcement Grids

Ground Reinforcement Grids A robust and versatile ground reinforcement system for car parks, driveways, overspill parking, pathways, equestrian yards, gateways and more. Made from 100% recycled... [ Read more ]
 0 reviews




Ground Reinforcement Grids

A robust and versatile ground reinforcement system for car parks, driveways, overspill parking, pathways, equestrian yards, gateways and more.
Made from 100% recycled plastic for maximum sustainability and minimum carbon footprint.
Use in combination with ALS soils, ALS seed, ALS natural turf and/or ALS aggregates.

Suitable for commercial and residential applications.

Specifications
  • Depths of 30/40/50mm available.
  • Each grid unit measures 330mm x 330mm.
  • 4.4/3.6/5.0mm wall thickness.
  • Up to 250/500/1000 T per square metre filled.
  • 5.04/5.22/9.55 Kg per square metre.
  • Up to 20T/20T/40T axle load.
  • Temperature range -50C to + 90 C.
  • 0.5% deformation.
  • 0.01% moisture absorbtion.
  • Resists acids, alkalis, alcohol, oil and petrol, de-icing salts, ammonia, acid rain.
  • 20 Year warranty up to 250T/500T/1000T loading when filled.
Full size samples available on request. Please contact us for more information. (Full size samples will incur a delivery cost)

Contractors must ensure that products are fit for purpose - if in doubt, please get in touch

Please note delivery prices are as accurate as possible at time of ordering, however this cost may be subject to change at any time due to weight/volume, fuel surcharges, currency changes and location.
Please let us know about any access restrictions at the delivery/check-out stage as failure to provide information may delay your order or incur extra delivery costs.

The administration team will contact you should any issue arise concerning delivery charges. Contact Arbour Landscape Solutions for more information. [email protected]
All materials are subject to availability at the time of order. The administration team will be in touch to arrange/advise of your delivery date.

Information coming soon.
